Specification
- MOTORS: 1000W x 2 with Hall Sensors (2520W x 2 peak output)
- BATTERY: 72V 28AH 18650 (2600mah)
- TOP SPEED: 75km/h (Private use) Can limit to 25kph
- MAX LOAD: 150kg (rider and gear)
- CONTROLLERS: 6 mosfet, 30a max current controllers x 2, sine wave, ip65, all waterproof connections.
- RANGE with 30km/h average speed: 80km @ 30 km/h
- FRAME: One piece aviation grade aluminium frame, heat treated
- SWING ARM: One piece 6082 aviation aluminum forged
- BRAKES: Front & rear Longan full hydraulic 2 Piston brakes w 160mm rotors and cooling fin pad
- SUSPENSION: 165mm travel length KKE hydraulic coil shock with rebound adjustment
- DASHBOARD: Large TFT Smart display with riding mode setting ability, setting parameters ability for each controller independently, smart cruise control, overheat protection built in, IP65
- HANDLEBAR: 31.8 diameter, Wider bars
- LIGHTS: 2000lumen front LED light, Side LED strip integrated with turn signal, motorcycle horn, IP55
- CABLE SYSTEM AND IP RATING: Plug n play connection for all electronic components(both sides) IP55 water resistance rating
- FOLDING SYSTEM: Patent designed thread lock taper folding system w 304 stainless steel parts
- TYRES: 11 inch tubeless tyre 90/65-6.5,street (off road available as extra + installation costs)
- CHARGER: 1 x 5A quick charger, dual charging port
- WEIGHT: 45KG
DIMENSIONS:
Overall size: 1346mm x 620mm x 1446mm.
Handle bar to deck: 1090mm height
Deck cover: 564mm x 312mm,766mm including foot rest
Ground clearance: 150mm at kickstand base, 170mm at heatsink.
Top of the deck to ground:292mm
Dimensions when Folded: 1346mm x 620mm x 640mm
LCD DISPLAY – AVAILABLE SETTINGS:
5 Riding modes parameter settings, independent for each controller
Seven point settings:
1) Rear motor starting power from 1 to 5
2) Front motor starting power from 1 to 5
3) Rear motor max output from 10 to 100(Percentage)
4) Front motor max output from 10 to 100(Percentage)
5) Max speed from 10 to 100(Percentage)
6) E-brake force, from 0 to 5
7) Turbo strength, from 0 to 5 (Turbo will add max speed and reduce torque of the motor.
-Smart cruise control: adjustable speed by using the a switch
-Overheat protection: Ability to set the max temperature for heat protection
star (indication of temperature for each controller).
-Low voltage protection: ability to set up the min power percentage for the low
power protection start
