Ventus Bikes VTB V9600 Controller

$1,999.00
$1,999.00

Controller Specification:

  • Maximum Bus Phase Current: 500A/960A
  • Peak Power: 44kW
  • Operating Temperature Range: -25°C to 80°C
  • Sinusoidal Vector Control
  • Voltage Range: 30V-99V (Limit), 48V-84V (Operating)



Controller Features:

  • Fine-tunable throttle response
  • High-reliability redundant design
  • Adaptive compensation for low throttle at low battery levels
  • 3 power modes, 5 riding modes for quick switching
  • 5 regenerative braking modes for quick switching
  • Linear regenerative electronic braking, energy-saving up to 30%
  • Customizable super-linear throttle handle
  • Customizable throttle curve, burst power, high-speed power compensation, speed percentage
  • Compatible with mainstream models including E-Ride Pro, Sur-Ron Light Bee, Ultra Bee, TALARIA Sting, TALARIA X3, 79 bike
  • Full-function APP, available for both Apple and Android devices
  • High-resolution color screen instrument panel
  • Sensory unlocking
  • Bluetooth binding with battery BMS for the instrument panel
  • CNC radiator
  • IP67 waterproof for the entire system

Package Contents:

  • Controller x1
  • Color Screen Instrument Panel x1
  • Instrument Panel Bracket x1
  • Throttle Handle x1
  • Switch Assembly x1
  • Thumb Throttle x1
  • Vehicle-specific Adapter Cable x1

How to Choose Your Hall Sensor

  • Surron Light Bee + Original Motor – To Hall Sensor (6 Pin Square)
  • Surron Light Bee + VTB Motor – No need adaptor / N/A
  • Surron Light Bee + Third Party Motor – To Encoder (8 Pin Square) KO (Encoder) / EBMX / Trop / Sotion
  • Surron Light Bee + Third Party Motor – To Hall Sensor (6 Pin Square) – KO (Hall)
  • Surron Ultra Bee + Original Motor – TBD
  • Surron Ultra Bee + VTB Motor – No need adaptor / N/A
  • Surron Ultra Bee + Third Party Motor – TBD
  • Talaria Sting + Original Motor – To Talaria Sting Motor Exclusive (8 Pin Square)
  • Talaria Sting + VTB Motor – No need adaptor / N/A
  • Talaria Sting + Third Party Motor – To Talaria Sting Motor Exclusive (8 Pin Square)
  • Talaria X3 + Original Motor – TBD / Not supported
  • Talaria X3 + VTB Motor – No need adaptor / N/A
  • Talaria X3 + Third Party Motor – TBD
  • 79 Bikes Falcon + Original – TBD
  • 79 Bikes Falcon + VTB Motor – No need adaptor / N/A
  • 79 Bikes Falcon + Third Party Motor (KO Encoder) / EBMX / Trop / Sotion) – To Encoder (8 Pin Square)
  • 79 Bikes Falcon + Third Party Motor (KO Hall) – To Hall Sensor (6 Pin Square)

VTB LCD Screen: Included
VTB Hand Controls: Included

Compatible Motors:

  • VTB Beast 28kW
  • VTB Beast 35kW
  • Sur-Ron Light Bee Factory
  • Sur-Ron Ultra Bee Factory
  • TALARIA Sting Factory
  • 79 bike Falcon Factory
  • QS165
  • LTXS
  • Sotion FW01
  • Sotion Talaria

Compatible Batteries:

Series 16-22, compatible with various models of both factory and modified batteries.



VTB DISPLAY

The VTB Ventus One features a sleek, multifunctional colored dashboard that connects via Bluetooth, providing real-time battery updates and performance data. With easy-to-read indicators and over-the-air updates, you can customize settings and always stay up to date for the best ride.

COLOUR
2 In Stock
