Sirris R46 SHOCK FOR SURRON ULTRA BEE
- Regular price
- $1,599.00
- Sale price
- $1,599.00
- Regular price
-
Trail Tune is a very versatile and aggressive tune that is sporty and supportive, designed to go fast over a wide variety of terrain.
RIDER WEIGHT SPECS:
Sirris offers six weight ranges to choose from when selecting your Trail Tune R46 shock. (Listed weight ranges are rider weight without riding gear on. Approximately 7 kg of riding gear is calculated into the weight ranges.)
59 kg - 73 kg (Light ships with 75 N/mm spring)
73 kg - 95 kg (Medium ships with 85 N/mm spring)
95 kg - 104 kg (Heavy ships with 90 N/mm spring)
104 kg - 113 kg (X Heavy ships with 95 N/mm spring)
113 kg - 127 kg (XX Heavy ships with 105 N/mm spring)
127 kg - 159 kg (XXX Heavy ships with 115 N/mm spring)
PRODUCT SPECS:
Architecture
Piggyback, steel spring
Stroke
85 mm
Length
320 mm
Weight
3.9 lbs / 1.76 kg without spring
Piston
High flow Ø46 mm, CNC 6061 billet aluminum, type 3 hard anodized coating
Piston band
Hard band
Shaft
Ø16 mm OD chrome-plated, induction hardened steel, hollow, Ø 5.5 mm ID
Shock body
Seamless 6061 aluminum, type 3 hard anodized coating, ACME thread
Spring retainer
Seamless 6061 aluminum, type 3 hard anodized coating, ACME thread, with locking feature, manual adjust
Bottom out
MCU bumper
Top out
Rubber bumper
Damping
Tunable compression and rebound
Reservoir
Pressurized with floating piston
Adjusters
External compression and rebound adjustment
Seals
NBR
